MAMO – ALO – Pile Suction Feeder (Optional Automatic Feeder for Vela Laminator and Flecto Creaser)

The MAMO Alo is an optional vacuum feeder, which makes the lamination process automatic.

Equipped with an adjustable front air flow allowing to process even the most difficult cards electrostatically charged.

The patented suction system optimizes the sheet feeding, even with slippery papers, and operates with low noise, since it does not require a vacuum pump.

The Alo automatic sheet feeder can hold sheets up to 999mm in length and a stack height of 150 mm, increasing the versatility of the machine

Highlights

·         Adjustable front air flow

·         Max paper width: 353 mm - (TBC)

·
Max laminating width: 340 mm - (TBC)

·
Max paper thickness: 500 gsm - (TBC)

·
Min paper thickness: 120 gsm - (TBC) (slight
differences may occur on paper type)

·
Sheet feeding speed: 10mt/min

·
Control panel

·
Power consumption: 2200 W

·
Power requirements : 230 V -
50/60 Hz

·
Dimension (mm): 600 x 600 x 1300 mm - (TBC)

·
Weight: 100 Kg

Typical Applications

• Business Cards
• Greeting Cards
• Book Covers
• Menu Cards
• Post Cards
